ExactFlat for SolidWorks 3D
Live Training via the Internet

SolidWorks 3D is a powerful 3D CAD platform for product design and development. ExactFlat 3D is an add-in for SolidWorks. It extends the capabilities for SolidWorks to 3D to 2D Digital Pattern Making. Digital Pattern making helps you make better patterns faster and we’ll show you how. See details below.




Rhino3D for Proliner Digitizer by Prodim Users – Standard Essentials Training

Length: Approx. 10 hours

Prerequisite:

  • None

Goal:

  • Use point and line segment data from a Proliner to quickly create 3D surfaces, markings, and cut-outs for use in 3D to 2D Digital Pattern Making.

Description:

  • You will learn the standard and essential commands for creating 3D surface geometry from Proliner digitized points and line segments.

  • This course is for current Proliner users or those considering purchasing a Proliner.

  • 2D Proliner data and 3D models will be provided, session details are shown below:

Topics Covered

  • Rhino UI, basic concepts of 3D Space

  • Modeling aids, curve concepts, trim, split, transformation commands

  • Rhino grid, units and tolerances

  • Basic NURBS surface commands Loft & Edge Surface

  • Curve fixing and rebuilding

  • Applying vector graphics and features to a model (Projecting curves with record history)

  • Surface joints, curve from object

  • Basic error detection and fixing (extract surface, untrim)

  • NURBS to mesh concepts

Rhino3D for Proliner Digitizer by Prodim Users – Extended In-depth Training

Length: Approx. 10 hours

Prerequisite:

  • Rhino3D for Proliner Digitizer by Prodim Users – Standard Essentials Training (10 hours)

Goal:

  • Be able to use the advance ExactFlat features to be able to fine tune 3D to 2D pattern making results

 Description:

  • You will learn the advanced commands for creating 3D surface geometry from Proliner digitized points and line segments.

  • This course will help increase your speed, and your proficiency.

  • This course is for experienced users and requires completion of of Rhino 3D for Proliner Digitizer - Standard Essentials Training.

  • 2D Proliner data and 3D models will be provided, session details are shown below:

 Topics Covered

  •  Extended Curve Tool

  • Curve from object tools

  • Sweep 1 and 2 rails, Network Surface, Patch

  • Surface Tools Blend Surface, Match Surface

  • Filleting Concepts

  • Solid tools

  • Surface and Curve Analysis

  • Advanced error detection and fixing
