ExactFlat for SolidWorks is software that helps you make better patterns faster. Go from 3D design to 2D production sewing patterns quickly, and easily.

ExactFlat for SolidWorks has many advantages. Here are the top 3:

• The 3D to 2D algorithms have superior accuracy. They have been refine over 15 plus years and can produce accurate pattern that do not require time consuming “tuning” in 2D.

• ExactFlat is easy to learn and quick to implement. Competitor products can cost $20,000 and take 80+ hours to learn, and more time still in use to become competent. For existing SolidWorks users, ExactFlat can be learned in as little as 4 hours.

• The ExactFlat workflow is fast because it stores inputs and outputs. ExactFlat stores, upstream outputs, and needed meta data to eliminate hand-off time between tasks and eliminate data translation and re-keying efforts. The result for users is a fast optimized workflow that helps you build compact nests in minutes, in real-time, dynamically; flatten 3D models in seconds; create notches, seams, and markings in less time than doing them manually.

ExactFlat 3D to 2D is digital patterning inside SOLIDWORKS 3D. Features include:

• Design in SOLIDWORKS 3D or import support file formats.

• Use ExactFlat Piece Creator to quickly convert faceted surface geometry to pattern pieces.

• Accurately flatten any surface including complex double curved 3D surfaces into accurate production ready 2D flat patterns.

• Add sewing features easily including seam allowances, alignment notches, darts, markings etc.

• Automatically apply edge labels to simplify manufacturing.

• Easily create drawings incorporating tables, balloons, and callouts.

• Export in standard DXF formats to create output for cutters or 2D fabric CAD packages.

• Create a markers and nests dynamically in real-time.

ExactFlat Professional is an upgrade that adds automated nesting and multi-job production management:

ExactFlat Professional extends the capabilities of SOLIDWORKS,  providing all of the capabilities found in ExactFlat Standard plus powerful automated nesting and production management tools. It is the fastest, easiest way to improve the productivity and profit of your nesting operations. Features include:

• Automated pattern nesting with powerful class leading nesting algorithms.

• Group jobs fast: Combine parts from different projects on a single marker for greater nest yield.

• Create estimates fast: Create marker costs in seconds.

• Sort parts fast: Increase the speed and efficiency of sorting with colour coded groups.

• Create automatic nests fast: Pull parts from a database, save time with templates and defaults, and update nests faster.

ExactFlat for SolidWorks helps you make better patterns faster.

Learn more about the ExactFlat for SolidWorks workflow

ExactFlat is an add-in for SolidWorks 3D. This is a big advantage for users. Unlike other programs which cost up to $20,000 and more than 80 hours just for training, ExactFlat is fast and easy to implement.

For Experienced SolidWorks users, it takes as little as 4 hours to learn, and production projects can be undertaken as soon as the same day. This is a significant advantage for any company considering digital pattern making.

Visit our YouTube channel playlists:

ExactFlat for SolidWorks: Video Playlists for Digital Pattern Making

For a comprehensive understanding of the ExactFlat software for SolidWorks YouTube Channel, we invite you to explore our available resources. These published documents will facilitate your search and extraction of the necessary information, making the process more convenient for you.

Check out the videos below from our YouTube channel: ExactFlat for SolidWorks.
